Key Features
- RS Domain R 170mm Fork
- RS SuperDeluxe PiggyBack, 150mm
- Shimano Deore 12 Speed
- Shimano Deore 4 Piston Disc Brakes
- Schwalbe Foldable Tires
- Syncros Dropper Post and Parts
- Syncros int. rear fender light
- Bosch Performance CX Drive Unit with 800Wh Battery
-
Frame
Alloy Frame
Integrated Suspension Technology
Virtual 4 Link kinematic / Adjustable head angle
Syncros Cable Integration System
Bosch Smart System / UDH Interface / 12x148mm with 55mm Chainline
Bosch PowerMore Ready -
Travel
Front: 170mm / Rear: 150mm -
Fork
RockShox Domain R Air / E-Bike / Reb Adj. / QR Axle 15x110mm axle
44mm offset / tapered steerer / 170mm travel -
Rear Shock
RockShox SuperDeluxe Piggy Back Trunnion / Reb Adj. / Large Air volume / T185X55mm
-
Drive Unit
Bosch Performance CX
EU: 25kmh / INT: 20mph -
Battery
PowerTube 800Wh -
Display
Bosch System Controller
Mini Remote -
Charger
4A Charger -
Rear Derailleur
Shimano Deore RD-M6100 SGS
Shadow Plus / 12 Speed -
Shifters
Shimano Deore SL-M6100-IR / Rapidfire Plus -
Crankset
FSA Alloy -
Chainguide
e*thirteen / e*spec Slider -
Chainring
FSA 12Speed 34T chainring -
Chain
Shimano CN-M6100 -
Cassette
Shimano CS-M6100 / 10-51 -
Brakes
Shimano Deore M6120 4-Piston Disc -
Rotor
Front: SM-RT64 CL 220mm / Rear: SM-RT64 CL 203mm -
Handlebar
Syncros Hixon 2.0 Alloy 6061
Size S & M 15mm rise / Size L & XL 25mm rise / back sweep 8° / 780mm
Syncros Endurance lock-on grips -
H'stem
Syncros AM 2.0
Syncros Cable Integration System
4° rise / 6061 Alloy / 31.8mm / 1 1/8" -
Seatpost
Syncros Duncan Dropper Post 2.5 / 31.6mm
S size 125mm / M size 150mm / L size 170mm / XL size 200mm -
Seat
Syncros Tofino-E 2.5 Regular -
Headset
Syncros - Acros Angle adjust & Cable Routing HS System / +-0.6° head angle adjustment
ZS56/28.6 – ZS56/40 MTB -
Hub (Front)
Formula CL-811 / 15x110mm -
Hub (Rear)
Formula ECT-148M / Boost 148x12mm -
Spokes
Stainless Black -
Rims
Syncros MD30 / 32H / 30mm / Pin Joint
Tubeless ready -
Front Tire
Schwalbe Magic Mary 29x2.5"
SuperGravity / PSF / Ultra Soft
Tubeless ready
120TPI Foldable Bead -
Rear Tire
Schwalbe Explore 29x2.5"
SuperGravity / PSF / Soft
Tubeless ready
120TPI Foldable Bead -
Lights
Syncros integrated rear fender light
Front Light Cable pre-installed -
Approx weight in KG
25.9 -
Approx weight in LBS
57.1 -
Max. System Weight
128kg
The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
