Frame
Carbon Main Frame, Alloy SST-CST
Integrated Suspension Technology
Virtual 4 Link kinematic, Adjustable head angle
Syncros Cable Integration System
Bosch Smart System, UDH Interface, 12x148mm with 55mm Chainline, Bosch PowerMore Ready, Kickstand mount -
Travel
Front: 150mm, Rear: 150mm -
Fork
FOX 36 Factory Air, eMTB+, Grip X2, HSC - LSC - HSR - LSR adjustable, QR Axle 15x110mm axle
44mm offset, tapered steerer, 150mm travel -
Rear Shock
FOX NUDE 6T Factory EVOL Trunnion
SCOTT custom w. travel, geo adj.
3 modes: Lockout-Traction Control-Descend
Low Speed Adj., Custom large Air volume, Reb. Adj.
Bearing Hardware, Travel 150-100-Lockout, T185X55mm
-
Remote System
Suspension & Dropper Remote
SCOTT TracLoc 2 Technology
3 modes -
Drive Unit
EU: 25kmh, INT: 20mph
Bosch Performance Line CX (BDU384Y) -
Battery
PowerTube 800Wh -
Display
Bosch System Controller, Mini Remote & Kiox 300 -
Charger
4A Charger -
Rear Derailleur
SRAM X0 Eagle AXS Transmission 12 Speed
Wireless Electronic Shift System -
Shifters
SRAM AXS Rocker Pod Controller -
Crankset
SRAM X0 Eagle, Alloy -
Chainguide
e*thirteen, e*spec Slider -
Chainring
SRAM Eagle Transmission 34T chainring -
Chain
SRAM CN GX Eagle Transmission -
Cassette
SRAM GX Eagle XS 1275 Transmission 10-52 -
Brakes
Shimano XT BR-M8220 4 Piston, Bosch ABS Pro -
Rotor
Front: SM-RT66 220mm, Rear: SM-RT66 203mm -
Handlebar
Syncros Hixon iC Carbon, Size S & M 15mm rise, Size L & XL 25mm rise
back sweep 8°, 780mm
Syncros Performance XC lock-on grips -
Seatpost
Syncros Duncan Dropper Post 1.5s, Travel Adjust, 31.6mm
S size 140mm, M size 180mm, L size 180mm, XL size 210mm -
Seat
Syncros Tofino-E 1.5 Regular
Titanium rails -
Headset
Stainless, +-0.6° head angle adjustment
Syncros - Acros Angle adjust & Cable Routing HS System
ZS56/28.6 – ZS56/40 MTB -
Wheelset
DT Swiss HXC1501, Hybrid, Carbon rims -
Front Tire
Maxxis Forekaster 29x2.6"
120TPI Foldable Bead
EXO, TR Tubeless ready
3C Maxx Terra -
Rear Tire
Maxxis Forekaster 29x2.6"
120TPI Foldable Bead
EXO, TR Tubeless ready
3C Maxx Terra -
Lights
Syncros integrated rear fender light
Front Light Cable pre-installed -
Approx weight in KG
23.7 -
Approx weight in LBS
52.25 -
Max. System Weight
130kg
The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
